pytorch 数据预处理，加载，训练，可视化流程

{:width=“50%” height=“50%”}

定义自定义数据集类

#======================
#1. 自定义数据集类
#======================
class CustomImageDataset(Dataset):
    def __init__(self, root_dir, transform=None):
        """
        自定义数据集初始化
        :param root_dir: 数据集根目录
        :param transform: 数据增强和预处理
        """
        self.root_dir = root_dir
        self.transform = transform
        self.classes = sorted(os.listdir(root_dir))
        self.class_to_idx = {cls_name: i for i, cls_name in enumerate(self.classes)}
        # 收集所有图像路径和标签
        self.image_paths = []
        self.labels = []
        for cls_name in self.classes:
            cls_dir = os.path.join(root_dir, cls_name)
            for img_name in os.listdir(cls_dir):
                if img_name.lower().endswith(('.jpg', '.png', '.jpeg')):
                    self.image_paths.append(os.path.join(cls_dir, img_name))
                    self.labels.append(self.class_to_idx[cls_name])
    def __len__(self):
        return len(self.image_paths)
    def __getitem__(self, idx):
        # 加载图像
        img_path = self.image_paths[idx]
        try:
            image = Image.open(img_path).convert('RGB')
        except Exception as e:
            print(f"Error loading image {img_path}: {e}")
            # 返回空白图像作为占位符
            image = Image.new('RGB', (224, 224), (0, 0, 0))
        # 应用数据增强和预处理
        if self.transform:
            image = self.transform(image)

        # 获取标签
        label = self.labels[idx]
        return image, label

定义训练和验证的数据增强

#======================
#2. 数据增强与预处理
#======================
def get_transforms():
    """返回训练和验证的数据增强管道"""
    # 训练集增强（更丰富）
    train_transform = transforms.Compose([
        transforms.RandomResizedCrop(224),
        transforms.RandomHorizontalFlip(p=0.5),
        transforms.RandomRotation(15),
        transforms.ColorJitter(brightness=0.2, contrast=0.2, saturation=0.2),
        transforms.ToTensor(),
        transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225])
    ])

    # 验证集预处理（无随机增强）
    val_transform = transforms.Compose([
        transforms.Resize(256),
        transforms.CenterCrop(224),
        transforms.ToTensor(),
        transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225])
    ])
    return train_transform, val_transform

定义模型、损失函数和优化器

#======================
#3. 模型定义
#======================
def create_model(num_classes):
    """创建模型（使用预训练ResNet18）"""
    model = resnet18(pretrained=True)
    num_ftrs = model.fc.in_features
    model.fc = nn.Linear(num_ftrs, num_classes)
    return model

训练循环，包括验证

#======================
#4. 训练函数
#======================
def train_model(model, dataloaders, criterion, optimizer, scheduler, device,
                num_epochs=25, checkpoint_path='checkpoint.pth', resume=False):
    """
    训练模型并支持中断恢复
    :param resume: 是否从检查点恢复训练
    """
    # 训练历史记录
    history = {
        'train_loss': [], 'val_loss': [],
        'train_acc': [], 'val_acc': [],
        'epoch': 0, 'best_acc': 0.0
    }
    # 从检查点恢复
    start_epoch = 0
    if resume and os.path.exists(checkpoint_path):
        print(f"Loading checkpoint from {checkpoint_path}")
        checkpoint = torch.load(checkpoint_path)
        model.load_state_dict(checkpoint['model_state_dict'])
        optimizer.load_state_dict(checkpoint['optimizer_state_dict'])
        scheduler.load_state_dict(checkpoint['scheduler_state_dict'])
        history = checkpoint['history']
        start_epoch = history['epoch'] + 1
        print(f"Resuming training from epoch {start_epoch}")
    # 训练循环
    for epoch in range(start_epoch, num_epochs):
        print(f'Epoch {epoch+1}/{num_epochs}')
        print('-' * 10)
        # 更新历史记录
        history['epoch'] = epoch
        # 每个epoch都有训练和验证阶段
        for phase in ['train', 'val']:
            if phase == 'train':
                model.train()  # 设置训练模式
            else:
                model.eval()   # 设置评估模式
            running_loss = 0.0
            running_corrects = 0
            # 迭代数据
            for inputs, labels in dataloaders[phase]:
                inputs = inputs.to(device)
                labels = labels.to(device)
                # 梯度清零
                optimizer.zero_grad()
                # 前向传播
                with torch.set_grad_enabled(phase == 'train'):
                    outputs = model(inputs)
                    _, preds = torch.max(outputs, 1)
                    loss = criterion(outputs, labels)
                    # 训练阶段反向传播和优化
                    if phase == 'train':
                        loss.backward()
                        optimizer.step()
                # 统计
                running_loss += loss.item() * inputs.size(0)
                running_corrects += torch.sum(preds == labels.data)
            if phase == 'train':
                scheduler.step()
            epoch_loss = running_loss / len(dataloaders[phase].dataset)
            epoch_acc = running_corrects.double() / len(dataloaders[phase].dataset)
            # 记录历史
            history[f'{phase}_loss'].append(epoch_loss)
            history[f'{phase}_acc'].append(epoch_acc.item())
            print(f'{phase} Loss: {epoch_loss:.4f} Acc: {epoch_acc:.4f}')
            # 保存最佳模型
            if phase == 'val' and epoch_acc > history['best_acc']:
                history['best_acc'] = epoch_acc.item()
                torch.save(model.state_dict(), 'best_model.pth')
                print(f"New best model saved with accuracy: {epoch_acc:.4f}")
        # 保存检查点（每个epoch结束后）
        checkpoint = {
            'epoch': epoch,
            'model_state_dict': model.state_dict(),
            'optimizer_state_dict': optimizer.state_dict(),
            'scheduler_state_dict': scheduler.state_dict(),
            'history': history
        }
        torch.save(checkpoint, checkpoint_path)
        print(f"Checkpoint saved at epoch {epoch+1}")
        print()
    # 保存最终模型
    torch.save(model.state_dict(), 'final_model.pth')
    print('Training finished!')
    return model, history

训练可视化

#======================
#5. 可视化训练历史
#======================
def plot_history(history):
    plt.figure(figsize=(12, 4))
    # 损失曲线
    plt.subplot(1, 2, 1)
    plt.plot(history['train_loss'], label='Train Loss')
    plt.plot(history['val_loss'], label='Validation Loss')
    plt.xlabel('Epochs')
    plt.ylabel('Loss')
    plt.legend()
    plt.title('Training and Validation Loss')
    # 准确率曲线
    plt.subplot(1, 2, 2)
    plt.plot(history['train_acc'], label='Train Accuracy')
    plt.plot(history['val_acc'], label='Validation Accuracy')
    plt.xlabel('Epochs')
    plt.ylabel('Accuracy')
    plt.legend()
    plt.title('Training and Validation Accuracy')

    plt.tight_layout()
    plt.savefig('training_history.png')
    plt.show()

整个流程

#======================
#6. 主函数
#======================
def main():
    # 设置随机种子（确保可复现性）
    torch.manual_seed(42)
    np.random.seed(42)

    # 检查设备
    device = torch.device("cuda" if torch.cuda.is_available() else "cpu")
    print(f"Using device: {device}")

    # 创建数据增强管道
    train_transform, val_transform = get_transforms()

    # 创建数据集
    train_dataset = CustomImageDataset(
        root_dir='path/to/your/train_data',  # 替换为你的训练数据路径
        transform=train_transform
    )

    val_dataset = CustomImageDataset(
        root_dir='path/to/your/val_data',    # 替换为你的验证数据路径
        transform=val_transform
    )

    # 创建数据加载器
    train_loader = DataLoader(
        train_dataset,
        batch_size=32,
        shuffle=True,
        num_workers=4,
        pin_memory=True
    )

    val_loader = DataLoader(
        val_dataset,
        batch_size=32,
        shuffle=False,
        num_workers=4,
        pin_memory=True
    )

    dataloaders = {'train': train_loader, 'val': val_loader}

    # 创建模型
    num_classes = len(train_dataset.classes)
    model = create_model(num_classes)
    model = model.to(device)

    # 定义损失函数和优化器
    criterion = nn.CrossEntropyLoss()
    optimizer = optim.Adam(model.parameters(), lr=0.001, weight_decay=1e-4)
    scheduler = optim.lr_scheduler.StepLR(optimizer, step_size=7, gamma=0.1)

    # 检查是否要恢复训练
    resume_training = False
    checkpoint_path = 'checkpoint.pth'

    # 检查是否存在检查点文件
    if os.path.exists(checkpoint_path):
        print("Checkpoint file found. Do you want to resume training? (y/n)")
        response = input().lower()
        if response == 'y':
            resume_training = True

    # 开始训练
    start_time = time.time()
    model, history = train_model(
        model=model,
        dataloaders=dataloaders,
        criterion=criterion,
        optimizer=optimizer,
        scheduler=scheduler,
        device=device,
        num_epochs=25,
        checkpoint_path=checkpoint_path,
        resume=resume_training
    )
    end_time = time.time()

    # 保存训练历史
    with open('training_history.json', 'w') as f:
        json.dump(history, f, indent=4)

    # 打印训练时间
    training_time = end_time - start_time
    print(f"Total training time: {training_time//3600}h {(training_time%3600)//60}m {training_time%60:.2f}s")

    # 可视化训练历史
    plot_history(history)

if __name__ == "__main__":
    main()

模型评估

#======================
#模型评估
#======================
def evaluate_model(model, dataloader, device):
    model.eval()
    correct = 0
    total = 0
    with torch.no_grad():
        for inputs, labels in dataloader:
            inputs, labels = inputs.to(device), labels.to(device)
            outputs = model(inputs)
            _, predicted = torch.max(outputs.data, 1)
            total += labels.size(0)
            correct += (predicted == labels).sum().item()

    accuracy = 100 * correct / total
    print(f'Test Accuracy: {accuracy:.2f}%')
    return accuracy
test_dataset = CustomImageDataset('path/to/test_data', transform=val_transform)
test_loader = DataLoader(test_dataset, batch_size=32, shuffle=False)
evaluate_model(model, test_loader, device)

高级功能扩展

混合精度训练​

from torch.cuda.amp import autocast, GradScaler
#在训练函数中添加
scaler = GradScaler()
#修改训练循环
with autocast():
    outputs = model(inputs)
    loss = criterion(outputs, labels)

scaler.scale(loss).backward()
scaler.step(optimizer)
scaler.update()

分布式训练​

import torch.distributed as dist
from torch.nn.parallel import DistributedDataParallel as DDP
#初始化分布式环境
dist.init_process_group(backend='nccl')
local_rank = int(os.environ['LOCAL_RANK'])
torch.cuda.set_device(local_rank)
#包装模型
model = DDP(model.to(local_rank), device_ids=[local_rank])
#修改数据加载器
train_sampler = torch.utils.data.distributed.DistributedSampler(train_dataset)
train_loader = DataLoader(..., sampler=train_sampler)
