基于VHDL的简易CPU设计
目录
基于VHDL的简易CPU设计 1
一、设计目的 1
二、设计内容 1
三、 详细设计 2
3.1设计的整体架构 2
3.2各模块的具体实现 3
四、 系统测试 35
4.1 测试环境 35
4.2 测试代码 35
4.3 测试结果 37
五、 总结 41
一、设计目的
1.本课程力图以“培养学生现代数字系统设计能力”为目标，贯彻以CPU设计为核心，以层次化、模块化设计方法为抓手的组织思路，培养学生设计与实现数字系统的能力。
2.本设计要求在进行了多个单元实验后，综合利用所学的理论知识，并结合在单元实验中所积累的成果（包括已经设计好的功能部件和调试方法），本文转载自http://www.biyezuopin.vip/onews.asp?id=15392设计出一个简易计算机系统。
二、设计内容
1.按给定的数据格式和指令系统，使用EDA工具设计一台用硬连线逻辑控制的简易计算机系统；
2.要求灵活运用各方面知识，使得所设计的计算机系统具有较佳的性能；
3.对所做设计的性能指标进行分析，整理出设计报告。
简易计算机系统
(一)数据格式
数据字采用8位二进制定点补码表示，其中最高位（第7位）为符号位，小数点可视为最左或最右，其数值表示范围分别为：-1≤X＜1或-128≤X＜127。
(二)寻址方式
指令的高4位为操作码，低4位分别用2位表示目的寄存器和源寄存器的编号或表示寻址方式。
Analysis & Synthesis report for CPU
Mon Dec 31 16:42:45 2018
Quartus II Version 9.0 Build 184 04/29/2009 Service Pack 1 SJ Web Edition
---------------------
; Table of Contents ;
---------------------
1. Legal Notice
2. Analysis & Synthesis Summary
3. Analysis & Synthesis Settings
4. Analysis & Synthesis Source Files Read
5. Analysis & Synthesis Resource Usage Summary
6. Analysis & Synthesis Resource Utilization by Entity
7. Analysis & Synthesis RAM Summary
8. User-Specified and Inferred Latches
9. Registers Removed During Synthesis
10. General Register Statistics
11. Inverted Register Statistics
12. Multiplexer Restructuring Statistics (Restructuring Performed)
13. Source assignments for LPM_RAM_IO:inst14|altram:sram|altsyncram:ram_block|altsyncram_9891:auto_generated
14. Parameter Settings for User Entity Instance: LPM_RAM_IO:inst14
15. Port Connectivity Checks: "ALU:inst|parallel_adder_vhdl:A3"
16. Port Connectivity Checks: "ALU:inst|parallel_adder_vhdl:A2"
17. Port Connectivity Checks: "ALU:inst|parallel_adder_vhdl:A1"
18. Analysis & Synthesis Messages
----------------
; Legal Notice ;
----------------
Copyright (C) 1991-2009 Altera Corporation
Your use of Altera Corporation's design tools, logic functions
and other software and tools, and its AMPP partner logic
functions, and any output files from any of the foregoing
(including device programming or simulation files), and any
associated documentation or information are expressly subject
to the terms and conditions of the Altera Program License
Subscription Agreement, Altera MegaCore Function License
Agreement, or other applicable license agreement, including,
without limitation, that your use is for the sole purpose of
programming logic devices manufactured by Altera and sold by
Altera or its authorized distributors. Please refer to the
applicable agreement for further details.
+----------------------------------------------------------------------------+
; Analysis & Synthesis Summary ;
+-----------------------------+----------------------------------------------+
; Analysis & Synthesis Status ; Successful - Mon Dec 31 16:42:45 2018 ;
; Quartus II Version ; 9.0 Build 184 04/29/2009 SP 1 SJ Web Edition ;
; Revision Name ; CPU ;
; Top-level Entity Name ; CPU ;
; Family ; Cyclone ;
; Total logic elements ; 266 ;
; Total pins ; 71 ;
; Total virtual pins ; 0 ;
; Total memory bits ; 2,048 ;
; Total PLLs ; 0 ;
+-----------------------------+----------------------------------------------+
+--------------------------------------------------------------------------------------------------------+
; Analysis & Synthesis Settings ;
+--------------------------------------------------------------+--------------------+--------------------+
; Option ; Setting ; Default Value ;
+--------------------------------------------------------------+--------------------+--------------------+
; Device ; EP1C3T144C8 ; ;
; Top-level entity name ; CPU ; CPU ;
; Family name ; Cyclone ; Stratix II ;
; Use Generated Physical Constraints File ; Off ; ;
; Use smart compilation ; Off ; Off ;
; Restructure Multiplexers ; Auto ; Auto ;
; Create Debugging Nodes for IP Cores ; Off ; Off ;
; Preserve fewer node names ; On ; On ;
; Disable OpenCore Plus hardware evaluation ; Off ; Off ;
; Verilog Version ; Verilog_2001 ; Verilog_2001 ;
; VHDL Version ; VHDL93 ; VHDL93 ;
; State Machine Processing ; Auto ; Auto ;
; Safe State Machine ; Off ; Off ;
; Extract Verilog State Machines ; On ; On ;
; Extract VHDL State Machines ; On ; On ;
; Ignore Verilog initial constructs ; Off ; Off ;
; Iteration limit for constant Verilog loops ; 5000 ; 5000 ;
; Iteration limit for non-constant Verilog loops ; 250 ; 250 ;
; Add Pass-Through Logic to Inferred RAMs ; On ; On ;
; Parallel Synthesis ; Off ; Off ;
; NOT Gate Push-Back ; On ; On ;
; Power-Up Don't Care ; On ; On ;
; Remove Redundant Logic Cells ; Off ; Off ;
; Remove Duplicate Registers ; On ; On ;
; Ignore CARRY Buffers ; Off ; Off ;
; Ignore CASCADE Buffers ; Off ; Off ;
; Ignore GLOBAL Buffers ; Off ; Off ;
; Ignore ROW GLOBAL Buffers ; Off ; Off ;
; Ignore LCELL Buffers ; Off ; Off ;
; Ignore SOFT Buffers ; On ; On ;
; Limit AHDL Integers to 32 Bits ; Off ; Off ;
; Optimization Technique ; Balanced ; Balanced ;
; Carry Chain Length ; 70 ; 70 ;
; Auto Carry Chains ; On ; On ;
; Auto Open-Drain Pins ; On ; On ;
; Perform WYSIWYG Primitive Resynthesis ; Off ; Off ;
; Auto ROM Replacement ; On ; On ;
; Auto RAM Replacement ; On ; On ;
; Auto Shift Register Replacement ; Auto ; Auto ;
; Auto Clock Enable Replacement ; On ; On ;
; Strict RAM Replacement ; Off ; Off ;
; Allow Synchronous Control Signals ; On ; On ;
; Force Use of Synchronous Clear Signals ; Off ; Off ;
; Auto RAM Block Balancing ; On ; On ;
; Auto RAM to Logic Cell Conversion ; Off ; Off ;
; Auto Resource Sharing ; Off ; Off ;
; Allow Any RAM Size For Recognition ; Off ; Off ;
; Allow Any ROM Size For Recognition ; Off ; Off ;
; Allow Any Shift Register Size For Recognition ; Off ; Off ;
; Use LogicLock Constraints during Resource Balancing ; On ; On ;
; Ignore translate_off and synthesis_off directives ; Off ; Off ;
; Show Parameter Settings Tables in Synthesis Report ; On ; On ;
; Ignore Maximum Fan-Out Assignments ; Off ; Off ;
; Synchronization Register Chain Length ; 2 ; 2 ;
; PowerPlay Power Optimization ; Normal compilation ; Normal compilation ;
; HDL message level ; Level2 ; Level2 ;
; Suppress Register Optimization Related Messages ; Off ; Off ;
; Number of Removed Registers Reported in Synthesis Report ; 100 ; 100 ;
; Number of Inverted Registers Reported in Synthesis Report ; 100 ; 100 ;
; Clock MUX Protection ; On ; On ;
; Block Design Naming ; Auto ; Auto ;
; Synthesis Effort ; Auto ; Auto ;
; Shift Register Replacement - Allow Asynchronous Clear Signal ; On ; On ;
; Analysis & Synthesis Message Level ; Medium ; Medium ;
+--------------------------------------------------------------+--------------------+--------------------+
+---------------------------------------------------------------------------------------------------------------------------------------------------------------+
; Analysis & Synthesis Source Files Read ;
+----------------------------------+-----------------+------------------------------------+---------------------------------------------------------------------+
; File Name with User-Entered Path ; Used in Netlist ; File Type ; File Name with Absolute Path ;
+----------------------------------+-----------------+------------------------------------+---------------------------------------------------------------------+
; cpu.mif ; yes ; User Memory Initialization File ; F:/大二/数字电路与逻辑设计/实验课/CPU/cpu.mif ;
; Z_Register.vhd ; yes ; User VHDL File ; F:/大二/数字电路与逻辑设计/实验课/CPU/Z_Register.vhd ;
; C_Register.vhd ; yes ; User VHDL File ; F:/大二/数字电路与逻辑设计/实验课/CPU/C_Register.vhd ;
; ALU.vhd ; yes ; User VHDL File ; F:/大二/数字电路与逻辑设计/实验课/CPU/ALU.vhd ;
; control_signal.vhd ; yes ; User VHDL File ; F:/大二/数字电路与逻辑设计/实验课/CPU/control_signal.vhd ;
; full_adder_vhdl.vhd ; yes ; User VHDL File ; F:/大二/数字电路与逻辑设计/实验课/CPU/full_adder_vhdl.vhd ;
; general_purpose_registers.vhd ; yes ; User VHDL File ; F:/大二/数字电路与逻辑设计/实验课/CPU/general_purpose_registers.vhd ;
; InstructionDecoder.vhd ; yes ; User VHDL File ; F:/大二/数字电路与逻辑设计/实验课/CPU/InstructionDecoder.vhd ;
; order_register.vhd ; yes ; User VHDL File ; F:/大二/数字电路与逻辑设计/实验课/CPU/order_register.vhd ;
; parallel_adder_vhdl.vhd ; yes ; User VHDL File ; F:/大二/数字电路与逻辑设计/实验课/CPU/parallel_adder_vhdl.vhd ;
; Program_Counter.vhd ; yes ; User VHDL File ; F:/大二/数字电路与逻辑设计/实验课/CPU/Program_Counter.vhd ;
; selector.vhd ; yes ; User VHDL File ; F:/大二/数字电路与逻辑设计/实验课/CPU/selector.vhd ;
; shift_lr.vhd ; yes ; User VHDL File ; F:/大二/数字电路与逻辑设计/实验课/CPU/shift_lr.vhd ;
; SM.vhd ; yes ; User VHDL File ; F:/大二/数字电路与逻辑设计/实验课/CPU/SM.vhd ;
; CPU.bdf ; yes ; User Block Diagram/Schematic File ; F:/大二/数字电路与逻辑设计/实验课/CPU/CPU.bdf ;
; LPM_RAM_IO.tdf ; yes ; Megafunction ; d:/quartus/quartus/libraries/megafunctions/LPM_RAM_IO.tdf ;
; altram.inc ; yes ; Megafunction ; d:/quartus/quartus/libraries/megafunctions/altram.inc ;
; lpm_mux.inc ; yes ; Megafunction ; d:/quartus/quartus/libraries/megafunctions/lpm_mux.inc ;
; lpm_decode.inc ; yes ; Megafunction ; d:/quartus/quartus/libraries/megafunctions/lpm_decode.inc ;
; aglobal90.inc ; yes ; Megafunction ; d:/quartus/quartus/libraries/megafunctions/aglobal90.inc ;
; altram.tdf ; yes ; Megafunction ; d:/quartus/quartus/libraries/megafunctions/altram.tdf ;
; memmodes.inc ; yes ; Megafunction ; d:/quartus/quartus/libraries/others/maxplus2/memmodes.inc ;
; altsyncram.inc ; yes ; Megafunction ; d:/quartus/quartus/libraries/megafunctions/altsyncram.inc ;
; altqpram.inc ; yes ; Megafunction ; d:/quartus/quartus/libraries/megafunctions/altqpram.inc ;
; altsyncram.tdf ; yes ; Megafunction ; d:/quartus/quartus/libraries/megafunctions/altsyncram.tdf ;
; stratix_ram_block.inc ; yes ; Megafunction ; d:/quartus/quartus/libraries/megafunctions/stratix_ram_block.inc ;
; a_rdenreg.inc ; yes ; Megafunction ; d:/quartus/quartus/libraries/megafunctions/a_rdenreg.inc ;
; altrom.inc ; yes ; Megafunction ; d:/quartus/quartus/libraries/megafunctions/altrom.inc ;
; altdpram.inc ; yes ; Megafunction ; d:/quartus/quartus/libraries/megafunctions/altdpram.inc ;
; db/altsyncram_9891.tdf ; yes ; Auto-Generated Megafunction ; F:/大二/数字电路与逻辑设计/实验课/CPU/db/altsyncram_9891.tdf ;
+----------------------------------+-----------------+------------------------------------+---------------------------------------------------------------------+
+-----------------------------------------------------+
; Analysis & Synthesis Resource Usage Summary ;
+---------------------------------------------+-------+
; Resource ; Usage ;
+---------------------------------------------+-------+
; Total logic elements ; 266 ;
; -- Combinational with no register ; 222 ;
; -- Register only ; 25 ;
; -- Combinational with a register ; 19 ;
; ; ;
; Logic element usage by number of LUT inputs ; ;
; -- 4 input functions ; 121 ;
; -- 3 input functions ; 81 ;
; -- 2 input functions ; 30 ;
; -- 1 input functions ; 8 ;
; -- 0 input functions ; 1 ;
; ; ;
; Logic elements by mode ; ;
; -- normal mode ; 259 ;
; -- arithmetic mode ; 7 ;
; -- qfbk mode ; 0 ;
; -- register cascade mode ; 0 ;
; -- synchronous clear/load mode ; 8 ;
; -- asynchronous clear/load mode ; 1 ;
; ; ;
; Total registers ; 44 ;
; Total logic cells in carry chains ; 8 ;
; I/O pins ; 71 ;
; Total memory bits ; 2048 ;
; Maximum fan-out node ; clk ;
; Maximum fan-out ; 52 ;
; Total fan-out ; 1082 ;
; Average fan-out ; 3.14 ;
+---------------------------------------------+-------+
+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
; Analysis & Synthesis Resource Utilization by Entity ;
+----------------------------------------------+-------------+--------------+-------------+------+--------------+--------------+-------------------+------------------+-----------------+------------+----------------------------------------------------------------------------------------+--------------+
; Compilation Hierarchy Node ; Logic Cells ; LC Registers ; Memory Bits ; Pins ; Virtual Pins ; LUT-Only LCs ; Register-Only LCs ; LUT/Register LCs ; Carry Chain LCs ; Packed LCs ; Full Hierarchy Name ; Library Name ;
+----------------------------------------------+-------------+--------------+-------------+------+--------------+--------------+-------------------+------------------+-----------------+------------+----------------------------------------------------------------------------------------+--------------+
; |CPU ; 266 (30) ; 44 ; 2048 ; 71 ; 0 ; 222 (30) ; 25 (0) ; 19 (0) ; 8 (0) ; 0 (0) ; |CPU ; work ;
; |ALU:inst| ; 70 (41) ; 0 ; 0 ; 0 ; 0 ; 70 (41) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst ; work ;
; |parallel_adder_vhdl:A1| ; 11 (0) ; 0 ; 0 ; 0 ; 0 ; 11 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A1 ; work ;
; |full_adder:FA2| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A1|full_adder:FA2 ; work ;
; |full_adder:FA3| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A1|full_adder:FA3 ; work ;
; |full_adder:FA4| ; 3 (2) ; 0 ; 0 ; 0 ; 0 ; 3 (2) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A1|full_adder:FA4 ; work ;
; |half_adder:HA2| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A1|full_adder:FA4|half_adder:HA2 ; work ;
; |full_adder:FA5| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A1|full_adder:FA5 ; work ;
; |full_adder:FA6| ; 3 (2) ; 0 ; 0 ; 0 ; 0 ; 3 (2) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A1|full_adder:FA6 ; work ;
; |half_adder:HA2| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A1|full_adder:FA6|half_adder:HA2 ; work ;
; |full_adder:FA8| ; 2 (1) ; 0 ; 0 ; 0 ; 0 ; 2 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A1|full_adder:FA8 ; work ;
; |half_adder:HA2| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A1|full_adder:FA8|half_adder:HA2 ; work ;
; |parallel_adder_vhdl:A2| ; 12 (0) ; 0 ; 0 ; 0 ; 0 ; 12 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2 ; work ;
; |full_adder:FA2| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2|full_adder:FA2 ; work ;
; |full_adder:FA3| ; 2 (1) ; 0 ; 0 ; 0 ; 0 ; 2 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2|full_adder:FA3 ; work ;
; |half_adder:HA2| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2|full_adder:FA3|half_adder:HA2 ; work ;
; |full_adder:FA4| ; 2 (1) ; 0 ; 0 ; 0 ; 0 ; 2 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2|full_adder:FA4 ; work ;
; |half_adder:HA1| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2|full_adder:FA4|half_adder:HA1 ; work ;
; |full_adder:FA5| ; 2 (1) ; 0 ; 0 ; 0 ; 0 ; 2 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2|full_adder:FA5 ; work ;
; |half_adder:HA2| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2|full_adder:FA5|half_adder:HA2 ; work ;
; |full_adder:FA6| ; 2 (1) ; 0 ; 0 ; 0 ; 0 ; 2 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2|full_adder:FA6 ; work ;
; |half_adder:HA1| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2|full_adder:FA6|half_adder:HA1 ; work ;
; |full_adder:FA7| ; 2 (1) ; 0 ; 0 ; 0 ; 0 ; 2 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2|full_adder:FA7 ; work ;
; |half_adder:HA2| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2|full_adder:FA7|half_adder:HA2 ; work ;
; |full_adder:FA8| ; 1 (0) ; 0 ; 0 ; 0 ; 0 ; 1 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2|full_adder:FA8 ; work ;
; |half_adder:HA1| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A2|full_adder:FA8|half_adder:HA1 ; work ;
; |parallel_adder_vhdl:A3| ; 6 (0) ; 0 ; 0 ; 0 ; 0 ; 6 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A3 ; work ;
; |full_adder:FA2| ; 1 (0) ; 0 ; 0 ; 0 ; 0 ; 1 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A3|full_adder:FA2 ; work ;
; |half_adder:HA2| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A3|full_adder:FA2|half_adder:HA2 ; work ;
; |full_adder:FA4| ; 2 (0) ; 0 ; 0 ; 0 ; 0 ; 2 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A3|full_adder:FA4 ; work ;
; |half_adder:HA2| ; 2 (2) ; 0 ; 0 ; 0 ; 0 ; 2 (2) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A3|full_adder:FA4|half_adder:HA2 ; work ;
; |full_adder:FA6| ; 2 (0) ; 0 ; 0 ; 0 ; 0 ; 2 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A3|full_adder:FA6 ; work ;
; |half_adder:HA2| ; 2 (2) ; 0 ; 0 ; 0 ; 0 ; 2 (2) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A3|full_adder:FA6|half_adder:HA2 ; work ;
; |full_adder:FA8| ; 1 (0) ; 0 ; 0 ; 0 ; 0 ; 1 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A3|full_adder:FA8 ; work ;
; |half_adder:HA2| ; 1 (1) ; 0 ; 0 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|ALU:inst|parallel_adder_vhdl:A3|full_adder:FA8|half_adder:HA2 ; work ;
; |C_Register:inst15| ; 1 (1) ; 1 ; 0 ; 0 ; 0 ; 0 (0) ; 0 (0) ; 1 (1) ; 0 (0) ; 0 (0) ; |CPU|C_Register:inst15 ; work ;
; |InstructionDecoder:inst3| ; 18 (18) ; 0 ; 0 ; 0 ; 0 ; 18 (18) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|InstructionDecoder:inst3 ; work ;
; |Program_Counter:inst5| ; 8 (8) ; 8 ; 0 ; 0 ; 0 ; 0 (0) ; 0 (0) ; 8 (8) ; 8 (8) ; 0 (0) ; |CPU|Program_Counter:inst5 ; work ;
; |SM:inst8| ; 1 (1) ; 1 ; 0 ; 0 ; 0 ; 0 (0) ; 0 (0) ; 1 (1) ; 0 (0) ; 0 (0) ; |CPU|SM:inst8 ; work ;
; |Z_Register:inst17| ; 1 (1) ; 1 ; 0 ; 0 ; 0 ; 0 (0) ; 0 (0) ; 1 (1) ; 0 (0) ; 0 (0) ; |CPU|Z_Register:inst17 ; work ;
; |control_signal:inst1| ; 23 (23) ; 0 ; 0 ; 0 ; 0 ; 23 (23) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|control_signal:inst1 ; work ;
; |general_purpose_registers:inst2| ; 60 (60) ; 24 ; 0 ; 0 ; 0 ; 36 (36) ; 17 (17) ; 7 (7) ; 0 (0) ; 0 (0) ; |CPU|general_purpose_registers:inst2 ; work ;
; |lpm_ram_io:inst14| ; 1 (1) ; 0 ; 2048 ; 0 ; 0 ; 1 (1) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|lpm_ram_io:inst14 ; work ;
; |altram:sram| ; 0 (0) ; 0 ; 2048 ; 0 ; 0 ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|lpm_ram_io:inst14|altram:sram ; work ;
; |altsyncram:ram_block| ; 0 (0) ; 0 ; 2048 ; 0 ; 0 ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|lpm_ram_io:inst14|altram:sram|altsyncram:ram_block ; work ;
; |altsyncram_9891:auto_generated| ; 0 (0) ; 0 ; 2048 ; 0 ; 0 ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|lpm_ram_io:inst14|altram:sram|altsyncram:ram_block|altsyncram_9891:auto_generated ; work ;
; |order_register:inst4| ; 11 (11) ; 9 ; 0 ; 0 ; 0 ; 2 (2) ; 8 (8) ; 1 (1) ; 0 (0) ; 0 (0) ; |CPU|order_register:inst4 ; work ;
; |selector:inst6| ; 25 (25) ; 0 ; 0 ; 0 ; 0 ; 25 (25) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|selector:inst6 ; work ;
; |shift_lr:inst7| ; 17 (17) ; 0 ; 0 ; 0 ; 0 ; 17 (17) ; 0 (0) ; 0 (0) ; 0 (0) ; 0 (0) ; |CPU|shift_lr:inst7 ; work ;
+----------------------------------------------+-------------+--------------+-------------+------+--------------+--------------+-------------------+------------------+-----------------+------------+----------------------------------------------------------------------------------------+--------------+
Note: For table entries with two numbers listed, the numbers in parentheses indicate the number of resources of the given type used by the specific entity alone. The numbers listed outside of parentheses indicate the total resources of the given type used by the specific entity and all of its sub-entities in the hierarchy.
+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
; Analysis & Synthesis RAM Summary ;
+----------------------------------------------------------------------------------------------+------+-------------+--------------+--------------+--------------+--------------+------+-----------+
; Name ; Type ; Mode ; Port A Depth ; Port A Width ; Port B Depth ; Port B Width ; Size ; MIF ;
+----------------------------------------------------------------------------------------------+------+-------------+--------------+--------------+--------------+--------------+------+-----------+
; lpm_ram_io:inst14|altram:sram|altsyncram:ram_block|altsyncram_9891:auto_generated|ALTSYNCRAM ; AUTO ; Single Port ; 256 ; 8 ; -- ; -- ; 2048 ; ./cpu.mif ;
+----------------------------------------------------------------------------------------------+------+-------------+--------------+--------------+--------------+--------------+------+-----------+
+----------------------------------------------------------------------------------------------------------+
; User-Specified and Inferred Latches ;
+-----------------------------------------------------+---------------------------+------------------------+
; Latch Name ; Latch Enable Signal ; Free of Timing Hazards ;
+-----------------------------------------------------+---------------------------+------------------------+
; ALU:inst|sum[7] ; ALU:inst|sum[7]~32 ; yes ;
; ALU:inst|sum[6] ; ALU:inst|sum[7]~32 ; yes ;
; ALU:inst|sum[5] ; ALU:inst|sum[7]~32 ; yes ;
; ALU:inst|sum[4] ; ALU:inst|sum[7]~32 ; yes ;
; ALU:inst|sum[3] ; ALU:inst|sum[7]~32 ; yes ;
; ALU:inst|sum[2] ; ALU:inst|sum[7]~32 ; yes ;
; ALU:inst|sum[1] ; ALU:inst|sum[7]~32 ; yes ;
; ALU:inst|sum[0] ; ALU:inst|sum[7]~32 ; yes ;
; ALU:inst|C ; ALU:inst|C~0 ; yes ;
; shift_lr:inst7|C ; shift_lr:inst7|C~0 ; yes ;
; selector:inst6|COUT[0] ; selector:inst6|COUT[7]~17 ; yes ;
; selector:inst6|COUT[1] ; selector:inst6|COUT[7]~17 ; yes ;
; selector:inst6|COUT[2] ; selector:inst6|COUT[7]~17 ; yes ;
; selector:inst6|COUT[3] ; selector:inst6|COUT[7]~17 ; yes ;
; selector:inst6|COUT[4] ; selector:inst6|COUT[7]~17 ; yes ;
; selector:inst6|COUT[5] ; selector:inst6|COUT[7]~17 ; yes ;
; selector:inst6|COUT[6] ; selector:inst6|COUT[7]~17 ; yes ;
; selector:inst6|COUT[7] ; selector:inst6|COUT[7]~17 ; yes ;
; control_signal:inst1|MADD[0] ; GND ; yes ;
; control_signal:inst1|MADD[1] ; GND ; yes ;
; Number of user-specified and inferred latches = 20 ; ; ;
+-----------------------------------------------------+---------------------------+------------------------+
Note: All latches listed above may not be present at the end of synthesis due to various synthesis optimizations.
+----------------------------------------------------------------------------------+
; Registers Removed During Synthesis ;
+---------------------------------------+------------------------------------------+
; Register name ; Reason for Removal ;
+---------------------------------------+------------------------------------------+
; order_register:inst4|Q[0]~en ; Lost fanout ;
; order_register:inst4|Q[1]~en ; Lost fanout ;
; order_register:inst4|Q[4]~en ; Lost fanout ;
; order_register:inst4|Q[5]~en ; Lost fanout ;
; order_register:inst4|Q[6]~en ; Lost fanout ;
; order_register:inst4|Q[7]~en ; Lost fanout ;
; order_register:inst4|Q[3]~en ; Merged with order_register:inst4|Q[2]~en ;
; Total Number of Removed Registers = 7 ; ;
+---------------------------------------+------------------------------------------+
+------------------------------------------------------+
; General Register Statistics ;
+----------------------------------------------+-------+
; Statistic ; Value ;
+----------------------------------------------+-------+
; Total registers ; 44 ;
; Number of registers using Synchronous Clear ; 0 ;
; Number of registers using Synchronous Load ; 8 ;
; Number of registers using Asynchronous Clear ; 0 ;
; Number of registers using Asynchronous Load ; 1 ;
; Number of registers using Clock Enable ; 33 ;
; Number of registers using Preset ; 0 ;
+----------------------------------------------+-------+
+--------------------------------------------------+
; Inverted Register Statistics ;
+----------------------------------------+---------+
; Inverted Register ; Fan out ;
+----------------------------------------+---------+
; order_register:inst4|Q[2]~en ; 9 ;
; general_purpose_registers:inst2|A[7] ; 6 ;
; general_purpose_registers:inst2|B[7] ; 3 ;
; general_purpose_registers:inst2|C[7] ; 3 ;
; general_purpose_registers:inst2|B[6] ; 3 ;
; general_purpose_registers:inst2|C[3] ; 3 ;
; general_purpose_registers:inst2|B[0] ; 3 ;
; general_purpose_registers:inst2|C[0] ; 3 ;
; Total number of inverted registers = 8 ; ;
+----------------------------------------+---------+
+-------------------------------------------------------------------------------------------------------------------------------------------------------------+
; Multiplexer Restructuring Statistics (Restructuring Performed) ;
+--------------------+-----------+---------------+----------------------+------------------------+------------+-----------------------------------------------+
; Multiplexer Inputs ; Bus Width ; Baseline Area ; Area if Restructured ; Saving if Restructured ; Registered ; Example Multiplexer Output ;
+--------------------+-----------+---------------+----------------------+------------------------+------------+-----------------------------------------------+
; 3:1 ; 6 bits ; 12 LEs ; 12 LEs ; 0 LEs ; No ; |CPU|shift_lr:inst7|shift[1]~8 ;
; 3:1 ; 8 bits ; 16 LEs ; 16 LEs ; 0 LEs ; No ; |CPU|general_purpose_registers:inst2|AO[5]~11 ;
; 3:1 ; 8 bits ; 16 LEs ; 16 LEs ; 0 LEs ; No ; |CPU|selector:inst6|COUT[0]~1 ;
; 3:1 ; 8 bits ; 16 LEs ; 16 LEs ; 0 LEs ; No ; |CPU|general_purpose_registers:inst2|BO[0]~1 ;
; 5:1 ; 7 bits ; 21 LEs ; 21 LEs ; 0 LEs ; No ; |CPU|ALU:inst|sum[4]~22 ;
+--------------------+-----------+---------------+----------------------+------------------------+------------+-----------------------------------------------+
+----------------------------------------------------------------------------------------------------------+
; Source assignments for LPM_RAM_IO:inst14|altram:sram|altsyncram:ram_block|altsyncram_9891:auto_generated ;
+---------------------------------+--------------------+------+--------------------------------------------+
; Assignment ; Value ; From ; To ;
+---------------------------------+--------------------+------+--------------------------------------------+
; OPTIMIZE_POWER_DURING_SYNTHESIS ; NORMAL_COMPILATION ; - ; - ;
+---------------------------------+--------------------+------+--------------------------------------------+
+----------------------------------------------------------------+
; Parameter Settings for User Entity Instance: LPM_RAM_IO:inst14 ;
+------------------------+--------------+------------------------+
; Parameter Name ; Value ; Type ;
+------------------------+--------------+------------------------+
; LPM_WIDTH ; 8 ; Signed Integer ;
; LPM_WIDTHAD ; 8 ; Signed Integer ;
; LPM_NUMWORDS ; 256 ; Signed Integer ;
; LPM_INDATA ; REGISTERED ; Untyped ;
; LPM_ADDRESS_CONTROL ; REGISTERED ; Untyped ;
; LPM_OUTDATA ; UNREGISTERED ; Untyped ;
; LPM_FILE ; ./cpu.mif ; Untyped ;
; USE_EAB ; ON ; Untyped ;
; DEVICE_FAMILY ; Cyclone ; Untyped ;
; AUTO_CARRY_CHAINS ; ON ; AUTO_CARRY ;
; IGNORE_CARRY_BUFFERS ; OFF ; IGNORE_CARRY ;
; AUTO_CASCADE_CHAINS ; ON ; AUTO_CASCADE ;
; IGNORE_CASCADE_BUFFERS ; OFF ; IGNORE_CASCADE ;
+------------------------+--------------+------------------------+
Note: In order to hide this table in the UI and the text report file, please set the "Show Parameter Settings Tables in Synthesis Report" option in "Analysis and Synthesis Settings -> More Settings" to "Off".
+----------------------------------------------------------------------------------------------------------------+
; Port Connectivity Checks: "ALU:inst|parallel_adder_vhdl:A3" ;
+------+--------+----------+-------------------------------------------------------------------------------------+
; Port ; Type ; Severity ; Details ;
+------+--------+----------+-------------------------------------------------------------------------------------+
; a ; Input ; Info ; Stuck at GND ;
; c0 ; Input ; Info ; Stuck at VCC ;
; c8 ; Output ; Info ; Connected to dangling logic. Logic that only feeds a dangling port will be removed. ;
+------+--------+----------+-------------------------------------------------------------------------------------+
+-------------------------------------------------------------+
; Port Connectivity Checks: "ALU:inst|parallel_adder_vhdl:A2" ;
+------+-------+----------+-----------------------------------+
; Port ; Type ; Severity ; Details ;
+------+-------+----------+-----------------------------------+
; c0 ; Input ; Info ; Stuck at VCC ;
+------+-------+----------+-----------------------------------+
+-------------------------------------------------------------+
; Port Connectivity Checks: "ALU:inst|parallel_adder_vhdl:A1" ;
+------+-------+----------+-----------------------------------+
; Port ; Type ; Severity ; Details ;
+------+-------+----------+-----------------------------------+
; c0 ; Input ; Info ; Stuck at GND ;
+------+-------+----------+-----------------------------------+
+-------------------------------+
; Analysis & Synthesis Messages ;
+-------------------------------+
Info: *******************************************************************
Info: Running Quartus II Analysis & Synthesis
Info: Version 9.0 Build 184 04/29/2009 Service Pack 1 SJ Web Edition
Info: Processing started: Mon Dec 31 16:42:41 2018
Info: Command: quartus_map --read_settings_files=on --write_settings_files=off CPU -c CPU
Info: Found 2 design units, including 1 entities, in source file Z_Register.vhd
Info: Found design unit 1: Z_Register-str
Info: Found entity 1: Z_Register
Info: Found 2 design units, including 1 entities, in source file C_Register.vhd
Info: Found design unit 1: C_Register-str
Info: Found entity 1: C_Register
Info: Found 2 design units, including 1 entities, in source file ALU.vhd
Info: Found design unit 1: ALU-str
Info: Found entity 1: ALU
Info: Found 2 design units, including 1 entities, in source file control_signal.vhd
Info: Found design unit 1: control_signal-beh
Info: Found entity 1: control_signal
Info: Found 4 design units, including 2 entities, in source file full_adder_vhdl.vhd
Info: Found design unit 1: half_adder-str1
Info: Found design unit 2: full_adder-str2
Info: Found entity 1: half_adder
Info: Found entity 2: full_adder
Info: Found 2 design units, including 1 entities, in source file general_purpose_registers.vhd
Info: Found design unit 1: general_purpose_registers-str
Info: Found entity 1: general_purpose_registers
Info: Found 2 design units, including 1 entities, in source file InstructionDecoder.vhd
Info: Found design unit 1: InstructionDecoder-RTL
Info: Found entity 1: InstructionDecoder
Info: Found 2 design units, including 1 entities, in source file order_register.vhd
Info: Found design unit 1: order_register-str
Info: Found entity 1: order_register
Info: Found 2 design units, including 1 entities, in source file parallel_adder_vhdl.vhd
Info: Found design unit 1: parallel_adder_vhdl-str
Info: Found entity 1: parallel_adder_vhdl
Info: Found 2 design units, including 1 entities, in source file Program_Counter.vhd
Info: Found design unit 1: Program_Counter-str
Info: Found entity 1: Program_Counter
Info: Found 4 design units, including 2 entities, in source file Register_8.vhd
Info: Found design unit 1: trigger-str
Info: Found design unit 2: Register_8-str
Info: Found entity 1: trigger
Info: Found entity 2: Register_8
Info: Found 2 design units, including 1 entities, in source file selector.vhd
Info: Found design unit 1: selector-beh
Info: Found entity 1: selector
Info: Found 2 design units, including 1 entities, in source file shift_lr.vhd
Info: Found design unit 1: shift_lr-beh
Info: Found entity 1: shift_lr
Info: Found 2 design units, including 1 entities, in source file SM.vhd
Info: Found design unit 1: SM-beh
Info: Found entity 1: SM
Info: Found 1 design units, including 1 entities, in source file CPU.bdf
Info: Found entity 1: CPU
Info: Elaborating entity "CPU" for the top level hierarchy
Info: Elaborating entity "control_signal" for hierarchy "control_signal:inst1"
Warning (10631): VHDL Process Statement warning at control_signal.vhd(17): inferring latch(es) for signal or variable "MADD", which holds its previous value in one or more paths through the process
Info (10041): Inferred latch for "MADD[0]" at control_signal.vhd(17)
Info (10041): Inferred latch for "MADD[1]" at control_signal.vhd(17)
Info: Elaborating entity "SM" for hierarchy "SM:inst8"
Info: Elaborating entity "InstructionDecoder" for hierarchy "InstructionDecoder:inst3"
Info: Elaborating entity "order_register" for hierarchy "order_register:inst4"
Info: Elaborating entity "LPM_RAM_IO" for hierarchy "LPM_RAM_IO:inst14"
Info: Elaborated megafunction instantiation "LPM_RAM_IO:inst14"
Info: Instantiated megafunction "LPM_RAM_IO:inst14" with the following parameter:
Info: Parameter "LPM_ADDRESS_CONTROL" = "REGISTERED"
Info: Parameter "LPM_FILE" = "./cpu.mif"
Info: Parameter "LPM_INDATA" = "REGISTERED"
Info: Parameter "LPM_NUMWORDS" = "256"
Info: Parameter "LPM_OUTDATA" = "UNREGISTERED"
Info: Parameter "LPM_WIDTH" = "8"
Info: Parameter "LPM_WIDTHAD" = "8"
Info: Elaborating entity "altram" for hierarchy "LPM_RAM_IO:inst14|altram:sram"
Warning: Assertion warning: altram does not support Cyclone device family -- attempting best-case memory conversions, but power-up states and read during write behavior will be different for Cyclone devices
Info: Elaborated megafunction instantiation "LPM_RAM_IO:inst14|altram:sram", which is child of megafunction instantiation "LPM_RAM_IO:inst14"
Info: Elaborating entity "altsyncram" for hierarchy "LPM_RAM_IO:inst14|altram:sram|altsyncram:ram_block"
Info: Elaborated megafunction instantiation "LPM_RAM_IO:inst14|altram:sram|altsyncram:ram_block", which is child of megafunction instantiation "LPM_RAM_IO:inst14"
Info: Found 1 design units, including 1 entities, in source file db/altsyncram_9891.tdf
Info: Found entity 1: altsyncram_9891
Info: Elaborating entity "altsyncram_9891" for hierarchy "LPM_RAM_IO:inst14|altram:sram|altsyncram:ram_block|altsyncram_9891:auto_generated"
Info: Elaborating entity "selector" for hierarchy "selector:inst6"
Warning (10492): VHDL Process Statement warning at selector.vhd(18): signal "S0" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10492): VHDL Process Statement warning at selector.vhd(20): signal "S1" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10492): VHDL Process Statement warning at selector.vhd(22): signal "S2" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10631): VHDL Process Statement warning at selector.vhd(15): inferring latch(es) for signal or variable "COUT", which holds its previous value in one or more paths through the process
Info (10041): Inferred latch for "COUT[0]" at selector.vhd(15)
Info (10041): Inferred latch for "COUT[1]" at selector.vhd(15)
Info (10041): Inferred latch for "COUT[2]" at selector.vhd(15)
Info (10041): Inferred latch for "COUT[3]" at selector.vhd(15)
Info (10041): Inferred latch for "COUT[4]" at selector.vhd(15)
Info (10041): Inferred latch for "COUT[5]" at selector.vhd(15)
Info (10041): Inferred latch for "COUT[6]" at selector.vhd(15)
Info (10041): Inferred latch for "COUT[7]" at selector.vhd(15)
Info: Elaborating entity "Program_Counter" for hierarchy "Program_Counter:inst5"
Info: Elaborating entity "general_purpose_registers" for hierarchy "general_purpose_registers:inst2"
Info (10041): Inferred latch for "BO[0]" at general_purpose_registers.vhd(40)
Info (10041): Inferred latch for "BO[1]" at general_purpose_registers.vhd(40)
Info (10041): Inferred latch for "BO[2]" at general_purpose_registers.vhd(40)
Info (10041): Inferred latch for "BO[3]" at general_purpose_registers.vhd(40)
Info (10041): Inferred latch for "BO[4]" at general_purpose_registers.vhd(40)
Info (10041): Inferred latch for "BO[5]" at general_purpose_registers.vhd(40)
Info (10041): Inferred latch for "BO[6]" at general_purpose_registers.vhd(40)
Info (10041): Inferred latch for "BO[7]" at general_purpose_registers.vhd(40)
Info (10041): Inferred latch for "AO[0]" at general_purpose_registers.vhd(37)
Info (10041): Inferred latch for "AO[1]" at general_purpose_registers.vhd(37)
Info (10041): Inferred latch for "AO[2]" at general_purpose_registers.vhd(37)
Info (10041): Inferred latch for "AO[3]" at general_purpose_registers.vhd(37)
Info (10041): Inferred latch for "AO[4]" at general_purpose_registers.vhd(37)
Info (10041): Inferred latch for "AO[5]" at general_purpose_registers.vhd(37)
Info (10041): Inferred latch for "AO[6]" at general_purpose_registers.vhd(37)
Info (10041): Inferred latch for "AO[7]" at general_purpose_registers.vhd(37)
Info: Elaborating entity "shift_lr" for hierarchy "shift_lr:inst7"
Warning (10492): VHDL Process Statement warning at shift_lr.vhd(17): signal "I" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10492): VHDL Process Statement warning at shift_lr.vhd(19): signal "I" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10492): VHDL Process Statement warning at shift_lr.vhd(20): signal "I" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10492): VHDL Process Statement warning at shift_lr.vhd(22): signal "I" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10492): VHDL Process Statement warning at shift_lr.vhd(23): signal "I" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10631): VHDL Process Statement warning at shift_lr.vhd(14): inferring latch(es) for signal or variable "shift", which holds its previous value in one or more paths through the process
Warning (10631): VHDL Process Statement warning at shift_lr.vhd(14): inferring latch(es) for signal or variable "C", which holds its previous value in one or more paths through the process
Info (10041): Inferred latch for "C" at shift_lr.vhd(14)
Info: Elaborating entity "ALU" for hierarchy "ALU:inst"
Warning (10036): Verilog HDL or VHDL warning at ALU.vhd(24): object "Cf" assigned a value but never read
Warning (10492): VHDL Process Statement warning at ALU.vhd(30): signal "add" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10492): VHDL Process Statement warning at ALU.vhd(31): signal "Ca" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10492): VHDL Process Statement warning at ALU.vhd(33): signal "subf" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10492): VHDL Process Statement warning at ALU.vhd(34): signal "Cs" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10492): VHDL Process Statement warning at ALU.vhd(36): signal "A" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10492): VHDL Process Statement warning at ALU.vhd(36): signal "B" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10492): VHDL Process Statement warning at ALU.vhd(39): signal "A" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10492): VHDL Process Statement warning at ALU.vhd(43): signal "A" is read inside the Process Statement but isn't in the Process Statement's sensitivity list
Warning (10631): VHDL Process Statement warning at ALU.vhd(26): inferring latch(es) for signal or variable "sum", which holds its previous value in one or more paths through the process
Warning (10631): VHDL Process Statement warning at ALU.vhd(26): inferring latch(es) for signal or variable "C", which holds its previous value in one or more paths through the process
Info (10041): Inferred latch for "C" at ALU.vhd(26)
Info (10041): Inferred latch for "sum[0]" at ALU.vhd(26)
Info (10041): Inferred latch for "sum[1]" at ALU.vhd(26)
Info (10041): Inferred latch for "sum[2]" at ALU.vhd(26)
Info (10041): Inferred latch for "sum[3]" at ALU.vhd(26)
Info (10041): Inferred latch for "sum[4]" at ALU.vhd(26)
Info (10041): Inferred latch for "sum[5]" at ALU.vhd(26)
Info (10041): Inferred latch for "sum[6]" at ALU.vhd(26)
Info (10041): Inferred latch for "sum[7]" at ALU.vhd(26)
Info: Elaborating entity "parallel_adder_vhdl" for hierarchy "ALU:inst|parallel_adder_vhdl:A1"
Info: Elaborating entity "full_adder" for hierarchy "ALU:inst|parallel_adder_vhdl:A1|full_adder:FA1"
Info: Elaborating entity "half_adder" for hierarchy "ALU:inst|parallel_adder_vhdl:A1|full_adder:FA1|half_adder:HA1"
Info: Elaborating entity "Z_Register" for hierarchy "Z_Register:inst17"
Info: Elaborating entity "C_Register" for hierarchy "C_Register:inst15"
Warning: Tri-state node(s) do not directly drive top-level pin(s)
Warning: Converted tri-state node feeding "C_Register:inst15|Q" into a selector
Warning: Converted tri-state buffer "order_register:inst4|x[0]" feeding internal logic into a wire
Warning: Converted tri-state buffer "order_register:inst4|x[1]" feeding internal logic into a wire
Warning: Converted tri-state buffer "order_register:inst4|x[4]" feeding internal logic into a wire
Warning: Converted tri-state buffer "order_register:inst4|x[5]" feeding internal logic into a wire
Warning: Converted tri-state buffer "order_register:inst4|x[6]" feeding internal logic into a wire
Warning: Converted tri-state buffer "order_register:inst4|x[7]" feeding internal logic into a wire
Warning: LATCH primitive "general_purpose_registers:inst2|BO[0]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|BO[1]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|BO[2]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|BO[3]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|BO[4]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|BO[5]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|BO[6]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|BO[7]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|AO[0]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|AO[1]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|AO[2]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|AO[3]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|AO[4]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|AO[5]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|AO[6]" is permanently enabled
Warning: LATCH primitive "general_purpose_registers:inst2|AO[7]" is permanently enabled
Warning: Tri-state node(s) do not directly drive top-level pin(s)
Warning: Converted the fan-out from the tri-state buffer "order_register:inst4|x[2]" to the node "InstructionDecoder:inst3|MOVB" into an OR gate
Warning: Converted the fan-out from the tri-state buffer "order_register:inst4|x[3]" to the node "general_purpose_registers:inst2|BO[7]" into an OR gate
Warning: Tri-state node(s) do not directly drive top-level pin(s)
Warning: Converted the fan-out from the tri-state buffer "inst24[7]" to the node "lpm_ram_io:inst14|altram:sram|altsyncram:ram_block|altsyncram_9891:auto_generated|q_a[7]" into an OR gate
Warning: Converted the fan-out from the tri-state buffer "inst24[6]" to the node "lpm_ram_io:inst14|altram:sram|altsyncram:ram_block|altsyncram_9891:auto_generated|q_a[6]" into an OR gate
Warning: Converted the fan-out from the tri-state buffer "inst24[5]" to the node "lpm_ram_io:inst14|altram:sram|altsyncram:ram_block|altsyncram_9891:auto_generated|q_a[5]" into an OR gate
Warning: Converted the fan-out from the tri-state buffer "inst24[4]" to the node "lpm_ram_io:inst14|altram:sram|altsyncram:ram_block|altsyncram_9891:auto_generated|q_a[4]" into an OR gate
Warning: Converted the fan-out from the tri-state buffer "inst24[3]" to the node "lpm_ram_io:inst14|altram:sram|altsyncram:ram_block|altsyncram_9891:auto_generated|q_a[3]" into an OR gate
Warning: Converted the fan-out from the tri-state buffer "inst24[2]" to the node "lpm_ram_io:inst14|altram:sram|altsyncram:ram_block|altsyncram_9891:auto_generated|q_a[2]" into an OR gate
Warning: Converted the fan-out from the tri-state buffer "inst24[1]" to the node "lpm_ram_io:inst14|altram:sram|altsyncram:ram_block|altsyncram_9891:auto_generated|q_a[1]" into an OR gate
Warning: Converted the fan-out from the tri-state buffer "inst24[0]" to the node "lpm_ram_io:inst14|altram:sram|altsyncram:ram_block|altsyncram_9891:auto_generated|q_a[0]" into an OR gate
Warning: Latch ALU:inst|sum[7] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|M
Warning: Latch ALU:inst|sum[6] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|M
Warning: Latch ALU:inst|sum[5] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|M
Warning: Latch ALU:inst|sum[4] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|M
Warning: Latch ALU:inst|sum[3] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|M
Warning: Latch ALU:inst|sum[2] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|M
Warning: Latch ALU:inst|sum[1] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|M
Warning: Latch ALU:inst|sum[0] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|M
Warning: Latch ALU:inst|C has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal order_register:inst4|Q[4]
Warning: Ports ENA and CLR on the latch are fed by the same signal order_register:inst4|Q[4]
Warning: Latch shift_lr:inst7|C has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal order_register:inst4|Q[0]
Warning: Latch selector:inst6|COUT[0] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|MADD[1]
Warning: Latch selector:inst6|COUT[1] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|MADD[1]
Warning: Latch selector:inst6|COUT[2] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|MADD[1]
Warning: Latch selector:inst6|COUT[3] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|MADD[1]
Warning: Latch selector:inst6|COUT[4] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|MADD[1]
Warning: Latch selector:inst6|COUT[5] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|MADD[1]
Warning: Latch selector:inst6|COUT[6] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|MADD[1]
Warning: Latch selector:inst6|COUT[7] has unsafe behavior
Warning: Ports D and ENA on the latch are fed by the same signal control_signal:inst1|MADD[1]
Warning: LATCH primitive "ALU:inst|sum[7]" is permanently enabled
Warning: LATCH primitive "ALU:inst|sum[6]" is permanently enabled
Warning: LATCH primitive "ALU:inst|sum[5]" is permanently enabled
Warning: LATCH primitive "ALU:inst|sum[4]" is permanently enabled
Warning: LATCH primitive "ALU:inst|sum[3]" is permanently enabled
Warning: LATCH primitive "ALU:inst|sum[2]" is permanently enabled
Warning: LATCH primitive "ALU:inst|sum[1]" is permanently enabled
Warning: LATCH primitive "ALU:inst|sum[0]" is permanently enabled
Info: 6 registers lost all their fanouts during netlist optimizations. The first 6 are displayed below.
Info: Register "order_register:inst4|Q[0]~en" lost all its fanouts during netlist optimizations.
Info: Register "order_register:inst4|Q[1]~en" lost all its fanouts during netlist optimizations.
Info: Register "order_register:inst4|Q[4]~en" lost all its fanouts during netlist optimizations.
Info: Register "order_register:inst4|Q[5]~en" lost all its fanouts during netlist optimizations.
Info: Register "order_register:inst4|Q[6]~en" lost all its fanouts during netlist optimizations.
Info: Register "order_register:inst4|Q[7]~en" lost all its fanouts during netlist optimizations.
Info: Implemented 345 device resources after synthesis - the final resource count might be different
Info: Implemented 9 input pins
Info: Implemented 62 output pins
Info: Implemented 266 logic cells
Info: Implemented 8 RAM segments
Info: Quartus II Analysis & Synthesis was successful. 0 errors, 105 warnings
Info: Peak virtual memory: 279 megabytes
Info: Processing ended: Mon Dec 31 16:42:45 2018
Info: Elapsed time: 00:00:04
Info: Total CPU time (on all processors): 00:00:04
本文含有隐藏内容，请 开通VIP 后查看
