YOLO11涨点优化：小目标 |新颖的多尺度前馈网络(MSFN) | 2024年4月最新成果。
nn/backbone/HCANet.py
加入以下代码到ultralytics/nn/backbone/HCANet.py
import sys
import torch
import torch.nn as nn
import torch.nn.functional as F
from pdb import set_trace as stx
import numbers
from einops import rearrange
import os
sys.path.append(os.getcwd())
# m_seed = 1
# # 设置seed
# torch.manual_seed(m_seed)
# torch.cuda.manual_seed_all(m_seed)
def to_3d(x):
return rearrange(x, 'b c h w -> b (h w) c')
def to_4d(x, h, w):
return rearrange(x, 'b (h w) c -> b c h w', h=h, w=w)
class BiasFree_LayerNorm(nn.Module):
def __init__(self, normalized_shape):
super(BiasFree_LayerNorm, self).__init__()
if isinstance(normalized_shape, numbers.Integral):
normalized_shape = (normalized_shape,)
normalized_shape = torch.Size(normalized_shape)
assert len(normalized_shape) == 1
self.weight = nn.Parameter(torch.ones(normalized_shape))
self.normalized_shape = normalized_shape
def forward(self, x):
sigma = x.var(-1, keepdim=True, unbiased=False)
return x / torch.sqrt(sigma + 1e-5) * self.weight
class WithBias_LayerNorm(nn.Module):
def __init__(self, normalized_shape):
super(WithBias_LayerNorm, self).__init__()
if isinstance(normalized_shape, numbers.Integral):
normalized_shape = (normalized_shape,)
normalized_shape = torch.Size(normalized_shape)
assert len(normalized_shape) == 1
self.weight = nn.Parameter(torch.ones(normalized_shape))
self.bias = nn.Parameter(torch.zeros(normalized_shape))
self.normalized_shape = normalized_shape
def forward(self, x):
mu = x.mean(-1, keepdim=True)
sigma = x.var(-1, keepdim=True, unbiased=False)
return (x - mu) / torch.sqrt(sigma + 1e-5) * self.weight + self.bias
class LayerNorm(nn.Module):
def __init__(self, dim, LayerNorm_type):
super(LayerNorm, self).__init__()
if LayerNorm_type == 'BiasFree':
self.body = BiasFree_LayerNorm(dim)
else:
self.body = WithBias_LayerNorm(dim)
def forward(self, x):
h, w = x.shape[-2:]
return to_4d(self.body(to_3d(x)), h, w)
##########################################################################
## Multi-Scale Feed-Forward Network (MSFN)
class MSFN(nn.Module):
def __init__(self, dim, ffn_expansion_factor=2.66, bias=False):
super(MSFN, self).__init__()
hidden_features = int(dim * ffn_expansion_factor)
self.project_in = nn.Conv3d(dim, hidden_features * 3, kernel_size=(1, 1, 1), bias=bias)
self.dwconv1 = nn.Conv3d(hidden_features, hidden_features, kernel_size=(3, 3, 3), stride=1, dilation=1,
padding=1, groups=hidden_features, bias=bias)
# self.dwconv2 = nn.Conv3d(hidden_features, hidden_features, kernel_size=(3,3,3), stride=1, dilation=2, padding=2, groups=hidden_features, bias=bias)
# self.dwconv3 = nn.Conv3d(hidden_features, hidden_features, kernel_size=(3,3,3), stride=1, dilation=3, padding=3, groups=hidden_features, bias=bias)
self.dwconv2 = nn.Conv2d(hidden_features, hidden_features, kernel_size=(3, 3), stride=1, dilation=2, padding=2,
groups=hidden_features, bias=bias)
self.dwconv3 = nn.Conv2d(hidden_features, hidden_features, kernel_size=(3, 3), stride=1, dilation=3, padding=3,
groups=hidden_features, bias=bias)
self.project_out = nn.Conv3d(hidden_features, dim, kernel_size=(1, 1, 1), bias=bias)
def forward(self, x):
x = x.unsqueeze(2)
x = self.project_in(x)
x1, x2, x3 = x.chunk(3, dim=1)
x1 = self.dwconv1(x1).squeeze(2)
x2 = self.dwconv2(x2.squeeze(2))
x3 = self.dwconv3(x3.squeeze(2))
# x1 = self.dwconv1(x1)
# x2 = self.dwconv2(x2)
# x3 = self.dwconv3(x3)
x = F.gelu(x1) * x2 * x3
x = x.unsqueeze(2)
x = self.project_out(x)
x = x.squeeze(2)
return x
##########################################################################
## Convolution and Attention Fusion Module (CAFM)
class CAFMAttention(nn.Module):
def __init__(self, dim, num_heads, bias=False):
super(CAFMAttention, self).__init__()
self.num_heads = num_heads
self.temperature = nn.Parameter(torch.ones(num_heads, 1, 1))
self.qkv = nn.Conv3d(dim, dim * 3, kernel_size=(1, 1, 1), bias=bias)
self.qkv_dwconv = nn.Conv3d(dim * 3, dim * 3, kernel_size=(3, 3, 3), stride=1, padding=1, groups=dim * 3,
bias=bias)
self.project_out = nn.Conv3d(dim, dim, kernel_size=(1, 1, 1), bias=bias)
self.fc = nn.Conv3d(3 * self.num_heads, 9, kernel_size=(1, 1, 1), bias=True)
self.dep_conv = nn.Conv3d(9 * dim // self.num_heads, dim, kernel_size=(3, 3, 3), bias=True,
groups=dim // self.num_heads, padding=1)
def forward(self, x):
b, c, h, w = x.shape
x = x.unsqueeze(2)
qkv = self.qkv_dwconv(self.qkv(x))
qkv = qkv.squeeze(2)
f_conv = qkv.permute(0, 2, 3, 1)
f_all = qkv.reshape(f_conv.shape[0], h * w, 3 * self.num_heads, -1).permute(0, 2, 1, 3)
f_all = self.fc(f_all.unsqueeze(2))
f_all = f_all.squeeze(2)
# local conv
f_conv = f_all.permute(0, 3, 1, 2).reshape(x.shape[0], 9 * x.shape[1] // self.num_heads, h, w)
f_conv = f_conv.unsqueeze(2)
out_conv = self.dep_conv(f_conv) # B, C, H, W
out_conv = out_conv.squeeze(2)
# global SA
q, k, v = qkv.chunk(3, dim=1)
q = rearrange(q, 'b (head c) h w -> b head c (h w)', head=self.num_heads)
k = rearrange(k, 'b (head c) h w -> b head c (h w)', head=self.num_heads)
v = rearrange(v, 'b (head c) h w -> b head c (h w)', head=self.num_heads)
q = torch.nn.functional.normalize(q, dim=-1)
k = torch.nn.functional.normalize(k, dim=-1)
attn = (q @ k.transpose(-2, -1)) * self.temperature
attn = attn.softmax(dim=-1)
out = (attn @ v)
out = rearrange(out, 'b head c (h w) -> b (head c) h w', head=self.num_heads, h=h, w=w)
out = out.unsqueeze(2)
out = self.project_out(out)
out = out.squeeze(2)
output = out + out_conv
return output
##########################################################################
## CAMixing Block
class CAMixingTransformerBlock(nn.Module):
def __init__(self, dim, num_heads, ffn_expansion_factor=2.66, bias=False, LayerNorm_type='WithBias'):
super(CAMixingTransformerBlock, self).__init__()
self.norm1 = LayerNorm(dim, LayerNorm_type)
self.attn = CAFMAttention(dim, num_heads, bias)
self.norm2 = LayerNorm(dim, LayerNorm_type)
self.ffn = MSFN(dim, ffn_expansion_factor, bias)
def forward(self, x):
x = x + self.attn(self.norm1(x))
x = x + self.ffn(self.norm2(x))
return x
修改task.py
- 首先进行引用定义
from ultralytics.nn.backbone.HCANet import MSFN
- 修改
def parse_model(d, ch, verbose=True)
只需要在你源码基础上加入MSFN，其他模块为博主的其他文章的优化点
n = n_ = max(round(n * depth), 1) if n > 1 else n # depth gain
if m in {
Classify,
Conv,
ConvTranspose,
GhostConv,
Bottleneck,
GhostBottleneck,
SPP,
SPPF,
C2fPSA,
C2PSA,
DWConv,
Focus,
BottleneckCSP,
C1,
C2,
C2f,
C3k2,
RepNCSPELAN4,
ELAN1,
ADown,
AConv,
SPPELAN,
C2fAttn,
C3,
C3TR,
C3Ghost,
nn.ConvTranspose2d,
DWConvTranspose2d,
C3x,
RepC3,
PSA,
SCDown,
C2fCIB,
MSFN
}:
c1, c2 = ch[f], args[0]
if c2 != nc: # if c2 not equal to number of classes (i.e. for Classify() output)
c2 = make_divisible(min(c2, max_channels) * width, 8)
if m is C2fAttn:
args[1] = make_divisible(min(args[1], max_channels // 2) * width, 8) # embed channels
args[2] = int(
max(round(min(args[2], max_channels // 2 // 32)) * width, 1) if args[2] > 1 else args[2]
) # num heads
args = [c1, c2, *args[1:]]
if m in {
BottleneckCSP,
C1,
C2,
C2f,
C3k2,
C2fAttn,
C3,
C3TR,
C3Ghost,
C3x,
RepC3,
C2fPSA,
C2fCIB,
C2PSA
}:
args.insert(2, n) # number of repeats
n = 1
if m is C3k2 and scale in "mlx": # for M/L/X sizes
args[3] = True
elif m is AIFI:
args = [ch[f], *args]
yolo11-MSFN.yaml
# Ultralytics YOLO 🚀, AGPL-3.0 license
# YOLO11 object detection model with P3-P5 outputs. For Usage examples see https://docs.ultralytics.com/tasks/detect
# Parameters
nc: 80 # number of classes
scales: # model compound scaling constants, i.e. 'model=yolo11n.yaml' will call yolo11.yaml with scale 'n'
# [depth, width, max_channels]
n: [0.50, 0.25, 1024] # summary: 319 layers, 2624080 parameters, 2624064 gradients, 6.6 GFLOPs
s: [0.50, 0.50, 1024] # summary: 319 layers, 9458752 parameters, 9458736 gradients, 21.7 GFLOPs
m: [0.50, 1.00, 512] # summary: 409 layers, 20114688 parameters, 20114672 gradients, 68.5 GFLOPs
l: [1.00, 1.00, 512] # summary: 631 layers, 25372160 parameters, 25372144 gradients, 87.6 GFLOPs
x: [1.00, 1.50, 512] # summary: 631 layers, 56966176 parameters, 56966160 gradients, 196.0 GFLOPs
# YOLO11n backbone
backbone:
# [from, repeats, module, args]
- [-1, 1, Conv, [64, 3, 2]] # 0-P1/2
- [-1, 1, Conv, [128, 3, 2]] # 1-P2/4
- [-1, 2, C3k2, [256, False, 0.25]]
- [-1, 1, Conv, [256, 3, 2]] # 3-P3/8
- [-1, 2, C3k2, [512, False, 0.25]]
- [-1, 1, Conv, [512, 3, 2]] # 5-P4/16
- [-1, 2, C3k2, [512, True]]
- [-1, 1, Conv, [1024, 3, 2]] # 7-P5/32
- [-1, 2, C3k2, [1024, True]]
- [-1, 1, SPPF, [1024, 5]] # 9
- [-1, 2, C2PSA, [1024]] # 10
# YOLO11n head
head:
- [-1, 1, nn.Upsample, [None, 2, "nearest"]]
- [[-1, 6], 1, Concat, [1]] # cat backbone P4
- [-1, 2, C3k2, [512, False]] # 13
- [-1, 1, nn.Upsample, [None, 2, "nearest"]]
- [[-1, 4], 1, Concat, [1]] # cat backbone P3
- [-1, 2, C3k2, [256, False]] # 16 (P3/8-small)
- [-1, 1, Conv, [256, 3, 2]]
- [[-1, 13], 1, Concat, [1]] # cat head P4
- [-1, 2, C3k2, [512, False]] # 19 (P4/16-medium)
- [-1, 1, Conv, [512, 3, 2]]
- [[-1, 10], 1, Concat, [1]] # cat head P5
- [-1, 2, C3k2, [1024, True]] # 22 (P5/32-large)
- [16, 1, PKIBlock, [256]] # 23
- [19, 1, PKIBlock, [512]] # 24
- [22, 1, PKIBlock, [1024]] # 25
- [[23, 24, 25], 1, Detect, [nc]] # Detect(P3, P4, P5)
